Three-dimensional lifting platform

The three-dimensional lifting platform and frame lifting platform have three directional movements. The first is the vertical horizontal movement along the ground track, the second is the upward and downward movement along the double pillars, and the third is the horizontal expansion movement perpendicular to the pillars, so as to realize the three-dimensional movement requirements.

Three-dimensional lifting platform

Three-dimensional lifting platform

Three-dimensional lifting platform

Relevant technical parameters

No.

Item

Parameter

1

Freedom

3

2

Driving mode

Electric

3

Maximum dimension of worktable

L1000×W800×H900

4

Operator working area

L900×W700×H700mm

5

The height of the platform from the ground at the lowest travel time

≤500mm

6

Longitudinal Moving Distance

29.2m

7

Longitudinal Moving Speed

15m/min

8

Transverse extension distance

1.2m

9

Lateral outreach velocity

3m/min

10

Vertical lift distance

0.5—4.0m

11

Vertical lift speed

5m/min

12

Maximum Load Weight

<200kg

13

Installed power

<3kw

14

Explosion-proof grade

level 1

15

Compressed Air Fast Interface

2
